# 安装必要的包
from IPython.display import clear_output

!pip install dm-haiku
!pip install optax
clear_output()

# 导入各种包
import tempfile

import haiku as hk
import jax
import jax.numpy as jnp
import matplotlib.pyplot as plt
import numpy as np
import optax
import pandas as pd
import seaborn as sns
from sklearn.model_selection import train_test_split
import seaborn as sns
import matplotlib.pyplot as plt

# 下载数据集
!featurize -t [token] dataset download ea22c102-a9c5-4ce5-aa31-576bd52ff7c1

100%|█████████████████████████████████████| 18.3M/18.3M [00:00<00:00, 38.0MiB/s]
🍬  下载完成，正在解压...
🏁  数据集已经成功添加

# 对数据进行载入以及前处理
# 对于一个节 k， X(k) 是一个由这些量组成的向量，在这种情况下，这些量是这个节的几何不变量

full_df = pd.read_csv('/home/featurize/data/knot_theory_invariants.csv')
display_name_from_short_name = {
    'chern_simons': 'Chern-Simons',
    'cusp_volume': 'Cusp volume',
    'hyperbolic_adjoint_torsion_degree': 'Adjoint Torsion Degree',
    'hyperbolic_torsion_degree': 'Torsion Degree',
    'injectivity_radius': 'Injectivity radius',
    'longitudinal_translation': 'Longitudinal translation',
    'meridinal_translation_imag': 'Re(Meridional translation)',
    'meridinal_translation_real': 'Im(Meridional translation)',
    'short_geodesic_imag_part': 'Im(Short geodesic)',
    'short_geodesic_real_part': 'Re(Short geodesic)',
    'Symmetry_0': 'Symmetry: $0$',
    'Symmetry_D3': 'Symmetry: $D_3$',
    'Symmetry_D4': 'Symmetry: $D_4$',
    'Symmetry_D6': 'Symmetry: $D_6$',
    'Symmetry_D8': 'Symmetry: $D_8$',
    'Symmetry_Z/2 + Z/2': 'Symmetry: $\\frac{Z}{2} + \\frac{Z}{2}$',
    'volume': 'Volume',
}
column_names = list(display_name_from_short_name)
target = 'signature'

# 分割训练数据集和测试数据集
random_seed = 2 # @param {type: "integer"}
random_state = np.random.RandomState(random_seed)
train_df, validation_and_test_df = train_test_split(
    full_df, random_state=random_state)
validation_df, test_df = train_test_split(
    validation_and_test_df, test_size=.5, random_state=random_state)

train_df.head(2)

print('训练集样本数量：', len(train_df))
print('测试集样本数量：', len(test_df))

训练集样本数量： 182809
测试集样本数量： 30469

!pip install autogluon
clear_output()

from autogluon.tabular import TabularPredictor

predictor = TabularPredictor(label=target).fit(
    train_df[column_names + [target]],
    tuning_data=validation_df[column_names + [target]],
    time_limit=60
)

No path specified. Models will be saved in: "AutogluonModels/ag-20220209_052125/"
Beginning AutoGluon training ... Time limit = 60s
AutoGluon will save models to "AutogluonModels/ag-20220209_052125/"
AutoGluon Version:  0.3.1
Train Data Rows:    182809
Train Data Columns: 17
Tuning Data Rows:    30468
Tuning Data Columns: 17
Preprocessing data ...
AutoGluon infers your prediction problem is: 'multiclass' (because dtype of label-column == int, but few unique label-values observed).
	First 10 (of 14) unique label values:  [-2, 0, 2, -8, 4, -4, -6, 8, 6, 10]
	If 'multiclass' is not the correct problem_type, please manually specify the problem_type argument in fit() (You may specify problem_type as one of: ['binary', 'multiclass', 'regression'])
Warning: Some classes in the training set have fewer than 10 examples. AutoGluon will only keep 12 out of 14 classes for training and will not try to predict the rare classes. To keep more classes, increase the number of datapoints from these rare classes in the training data or reduce label_count_threshold.
Fraction of data from classes with at least 10 examples that will be kept for training models: 0.9999452980980149
Train Data Class Count: 12
Using Feature Generators to preprocess the data ...
Fitting AutoMLPipelineFeatureGenerator...
	Available Memory:                    25132.68 MB
	Train Data (Original)  Memory Usage: 29.0 MB (0.1% of available memory)
	Inferring data type of each feature based on column values. Set feature_metadata_in to manually specify special dtypes of the features.
	Stage 1 Generators:
		Fitting AsTypeFeatureGenerator...
			Note: Converting 6 features to boolean dtype as they only contain 2 unique values.
	Stage 2 Generators:
		Fitting FillNaFeatureGenerator...
	Stage 3 Generators:
		Fitting IdentityFeatureGenerator...
	Stage 4 Generators:
		Fitting DropUniqueFeatureGenerator...
	Types of features in original data (raw dtype, special dtypes):
		('float', []) : 15 | ['chern_simons', 'cusp_volume', 'injectivity_radius', 'longitudinal_translation', 'meridinal_translation_imag', ...]
		('int', [])   :  2 | ['hyperbolic_adjoint_torsion_degree', 'hyperbolic_torsion_degree']
	Types of features in processed data (raw dtype, special dtypes):
		('float', [])     : 9 | ['chern_simons', 'cusp_volume', 'injectivity_radius', 'longitudinal_translation', 'meridinal_translation_imag', ...]
		('int', [])       : 2 | ['hyperbolic_adjoint_torsion_degree', 'hyperbolic_torsion_degree']
		('int', ['bool']) : 6 | ['Symmetry_0', 'Symmetry_D3', 'Symmetry_D4', 'Symmetry_D6', 'Symmetry_D8', ...]
	0.6s = Fit runtime
	17 features in original data used to generate 17 features in processed data.
	Train Data (Processed) Memory Usage: 20.05 MB (0.1% of available memory)
Data preprocessing and feature engineering runtime = 0.79s ...
AutoGluon will gauge predictive performance using evaluation metric: 'accuracy'
	To change this, specify the eval_metric argument of fit()
Fitting 13 L1 models ...
Fitting model: KNeighborsUnif ... Training model for up to 59.21s of the 59.2s of remaining time.
	0.9354	 = Validation score   (accuracy)
	16.84s	 = Training   runtime
	1.03s	 = Validation runtime
Fitting model: KNeighborsDist ... Training model for up to 41.24s of the 41.23s of remaining time.
	0.9483	 = Validation score   (accuracy)
	16.64s	 = Training   runtime
	0.83s	 = Validation runtime
Fitting model: NeuralNetFastAI ... Training model for up to 23.7s of the 23.7s of remaining time.
	Ran out of time, stopping training early. (Stopping on epoch 0)
	0.9095	 = Validation score   (accuracy)
	31.75s	 = Training   runtime
	0.5s	 = Validation runtime
Fitting model: WeightedEnsemble_L2 ... Training model for up to 59.21s of the -11.39s of remaining time.
	0.9624	 = Validation score   (accuracy)
	4.5s	 = Training   runtime
	0.01s	 = Validation runtime
AutoGluon training complete, total runtime = 76.0s ...
TabularPredictor saved. To load, use: predictor = TabularPredictor.load("AutogluonModels/ag-20220209_052125/")

leaderboard = predictor.leaderboard(test_df, silent=True)
feature_importance = predictor.feature_importance(test_df, silent=True)

!sudo apt-get install -y graphviz graphviz-dev
!pip install pygraphviz
clear_output()

from PIL import Image
Image.open(predictor.plot_ensemble_model())

# 训练过的模型的详细信息
leaderboard

# 特征的重要程度
plt.figure(figsize=(16,8))
sns.barplot(x=feature_importance.importance.values, y=feature_importance.importance.index);
