import os
if not os.path.exists("/home/featurize/data/anno.zip"):
!featurize dataset download 757181ec-0841-4468-b701-54ea53ad2d3c
if not os.path.exists("/home/featurize/data/forgery_round1_train_20220217.zip"):
!featurize dataset download e4dc9a7b-ded4-453d-b887-1f3fb04a5f94from IPython.display import clear_output
%pip install minetorch seaborn albumentations segmentation_models_pytorch
clear_output()import os
import cv2
import torch
import random
import minetorch
import numpy as np
import pandas as pd
import seaborn as sns
import albumentations as albu
import matplotlib.pyplot as plt
import segmentation_models_pytorch as smp
from albumentations.pytorch import ToTensorV2
from albumentations import Normalize, Compose
from torch.utils.data import DataLoader, Dataset
from sklearn.model_selection import train_test_split
from torch.optim.lr_scheduler import CosineAnnealingWarmRestartsCONFIG = {
'DIR': 'Experiments',
'img_size': 224,
'model_name': 'timm-efficientnet-b0',
'fold': 0,
'lr': 1e-4,
'batch_size': 128,
'epoch': 20
}class AliDataset(Dataset):
def __init__(self, df, transforms, train=False):
self.df = df
self.transforms = transforms
self.train = train
def __getitem__(self, idx):
row = self.df.iloc[idx]
fn = row.image
image = cv2.imread(os.path.join(row['image_path'], str(fn) + '.jpg'))
image = cv2.cvtColor(image, cv2.COLOR_BGR2RGB)
masks = cv2.imread(os.path.join(row['mask_path'], str(fn) + '.png'), cv2.IMREAD_GRAYSCALE)/255
augmented = self.transforms(image=image, mask=masks)
img, mask = augmented['image'], augmented['mask']
return img.float(), mask.float()
def __len__(self):
return len(self.df)
def create_transformation(phase):
transforms = albu.Compose([
albu.RandomBrightnessContrast(p=0.5),
albu.OneOf([
albu.Rotate(limit=[90,90], p=0.5),
albu.Rotate(limit=[270,270], p=0.5),
], p=0.5),
albu.RandomResizedCrop(CONFIG['img_size'], CONFIG['img_size'], scale=(0.8, 1.0), ratio=(0.75, 1.3333333333333333)),
albu.Resize(CONFIG['img_size'], CONFIG['img_size'], p=1),
ToTensorV2()
])
if phase == 'val':
transforms = albu.Compose([
albu.Resize(CONFIG['img_size'], CONFIG['img_size'], p=1),
ToTensorV2()
])
return transformsfrom minetorch.plugin import Plugin
def dice_coeff(pred, target):
smooth = 1e-12
num = pred.size(0)
m1 = pred.view(num, -1).float() # Flatten
m2 = target.view(num, -1).float() # Flatten
intersection = (m1 * m2).sum().float()
return (2. * intersection + smooth) / (m1.sum() + m2.sum() + smooth)
def iou_pytorch(outputs: torch.Tensor, labels: torch.Tensor):
SMOOTH = 1e-12
outputs = outputs.squeeze(1) # BATCH x 1 x H x W => BATCH x H x W
intersection = (outputs * labels).float().sum((1, 2))
union = (outputs + labels).float().sum((1, 2))
iou = (intersection + SMOOTH) / (union - intersection + SMOOTH)
return iou
class MultiClassesSegmentationMetricWithLogic(Plugin):
"""MultiClassesClassificationMetric
This can be used directly if your loss function is torch.nn.CrossEntropy
"""
def __init__(self,
miou=True,
mf1=True,
sheet_key_prefix=''):
super().__init__(sheet_key_prefix)
self.miou = miou
self.mf1 = mf1
def before_init(self):
self.create_sheet_column('miou', 'miou')
def before_epoch_start(self, epoch):
self.iou = 0
self.f1 = 0
self.len = 0
def after_val_iteration_ended(self, predicts, data, **ignore):
predicts = (torch.sigmoid(predicts) > 0.5).int().detach().cpu()
targets = data[1].detach().cpu()
eps = 1e-12
iou = iou_pytorch(predicts, targets)
f1 = dice_coeff(predicts, targets)
self.f1 += f1
self.iou += iou.sum()
self.len += 1
def after_epoch_end(self, val_loss, **ignore):
self.miou and self._iou()
self.mf1 and self._f1()
def _f1(self):
mf1 = self.f1 / self.len
png_file = self.scalars(
{
'mf1': mf1,
}, 'mf1'
)
if png_file:
self.update_sheet('f1', {'raw': png_file, 'processor': 'upload_image'})
def _iou(self):
miou = torch.sum(self.iou) / 800
png_file = self.scalars(
{
'miou': miou,
}, 'miou'
)
if png_file:
self.update_sheet('iou', {'raw': png_file, 'processor': 'upload_image'})df = pd.read_csv('/home/featurize/data/train.csv')
df['image_path'] = '/home/featurize/data/train/img/'
df['mask_path'] = f'/home/featurize/data/train/mask/'
train_df = df[df.fold != CONFIG['fold']].reset_index(drop=True)
val_df = df[df.fold == CONFIG['fold']].reset_index(drop=True)
trainset = AliDataset(train_df, create_transformation('train'),train=True)
valset = AliDataset(val_df, create_transformation('val'))
train_loader = DataLoader(
trainset,
batch_size=CONFIG['batch_size'],
num_workers=8,
shuffle=True,
pin_memory=True,
)
val_loader = DataLoader(
valset,
batch_size=CONFIG['batch_size'],
num_workers=8,
pin_memory=True
)df.head()| image | ratio | fold | image_path | mask_path | |
|---|---|---|---|---|---|
| 0 | 146 | 1.1 | 0 | /home/featurize/data/train/img/ | /home/featurize/data/train/mask/ |
| 1 | 2168 | 7.0 | 0 | /home/featurize/data/train/img/ | /home/featurize/data/train/mask/ |
| 2 | 1689 | 6.8 | 0 | /home/featurize/data/train/img/ | /home/featurize/data/train/mask/ |
| 3 | 953 | 1.4 | 0 | /home/featurize/data/train/img/ | /home/featurize/data/train/mask/ |
| 4 | 2668 | 8.3 | 0 | /home/featurize/data/train/img/ | /home/featurize/data/train/mask/ |
model = smp.UnetPlusPlus(
CONFIG['model_name'],
classes=1,
encoder_weights='imagenet',
activation=None,
)optimizer = torch.optim.AdamW(model.parameters(), lr=CONFIG['lr'], betas=(0.9, 0.999), eps=1e-08, amsgrad=False)
scheduler = CosineAnnealingWarmRestarts(optimizer, T_0=5, T_mult=2, eta_min=1e-6, last_epoch=-1)
def after_epoch_end(miner, **payload):
scheduler.step(miner.current_epoch)bce_loss = torch.nn.BCEWithLogitsLoss(pos_weight=torch.tensor([3.]).cuda()).cuda()
def forward_fn(trainer, data):
images, masks = data
images, masks = images.cuda(), masks.cuda()
mask = model(images).squeeze(1)
loss = bce_loss(mask, masks)
return mask, lossminer = minetorch.Miner(
code=os.getenv('CODE', f'fold-{CONFIG["fold"]}'),
alchemistic_directory=os.getenv('ALCHEMISTIC_DIRECTORY', f'/home/featurize/{CONFIG['DIR']}/{CONFIG["model_name"]}-{CONFIG["img_size"]}'),
model=model.cuda(),
forward=forward_fn,
optimizer=optimizer,
train_dataloader=train_loader,
val_dataloader=val_loader,
max_epochs=CONFIG['epoch'],
in_notebook=True,
loss_func=None,
amp=True,
plugins=[MultiClassesSegmentationMetricWithLogic()],
hooks={
'after_epoch_end': after_epoch_end,
},
trival=False,
resume=False
)miner.train()import IPython
IPython.display.Image('/home/featurize/Experiments/timm-efficientnet-b0-224/fold-0/graphs/loss.png')IPython.display.Image('/home/featurize/Experiments/timm-efficientnet-b0-224/fold-0/graphs/miou.png')IPython.display.Image('/home/featurize/Experiments/timm-efficientnet-b0-224/fold-0/graphs/mf1.png')
